Foam has the ability to form an aqueous film which quickly over water-insoluble hydrocarbon fuel surfaces causing rapid fire extinguishment and vapor suppression for class B fires. Also it provides excellent penetrating and wetting qualities when used on class A fires. Hence, foam extinguishers are ideal for fires involving volatile liquids and freely burning materials such as lubricant, oil fires, paper, cloth, wood, etc.
Features
- Only for fighting class A and B fire
- Drawn Steel Cylinders
- Squeeze Grip type discharge Valve and cap made out of Brass with Chrome Plated
- High quality epoxy polyester powder coated
- BIS 15683 Approved
- Maintenance should be done as per IS 2190:2010
User Friendly : Easy and More Economical to Maintain and Service
Warning : Do not use on electrical fires.
| TYPE | STORED PRESSURE | CARTRIDGE TYPE |
| Capacity | 9L | 9L |
| Model No. | FSI-SP-MF-9 | FSI-C-MF-9 |
| Diameter (mm) | 175 | 175 |
| Height (mm) | 405 | 15 |
| Empty Weight (Kg) | 4.7 | 7.6 |
| Filled Weight (Kg) | 13.7 | 16.6 |
| Operating Temperature | +5ºC TO +555ºC | +5ºC TO +555ºC |
| Working Pressure At 27°C | 15 | 15 |
| Maximum Service Pressure | 1.6 Mpa | 2.1 Mpa |
| Test Pressure | 35 bar | 35 bar |
| Average Discharge Time (s) | 60 | 60 |
| Discharge Range (mts) | 6 | 6 |
| Fire Rating | 2A, 34B | 2A, 21B |
